Monday, May 11, 2015

Compatibility with Olympus E-M5 Mark II / PT-EP13

INON INC. is pleased to announce compatibility of existing INON products with Olympus E-M5 Mark II / PT-EP13 (*1).

■ External Strobe/LED flashlight Compatibility with E-M5 Mark II / PT-EP13 (*1) ■

The highly accurate "S-TTL" Auto mode of INON Z-240 / D-2000 / S-2000 is supported when connecting via INON "Optical D Cable Type L/Double Hole Rubber Bush Set" products below. (*2)(*3)(*4)

Optical D Cable Type L/Double Hole Rubber Bush Set (*2)
--Available in the market
--JAN code: 456212143 561 2

Optical D Cable L Type L/Double Hole Rubber Bush Set (*2)
--Available in the market
--JAN code: 456212143 562 9

Optical D Cable SS Type L/Double Hole Rubber Bush Set (*2)
--Available in the market
--JAN code: 456212143 563 6

Optical D Cable LL Type L/Double Hole Rubber Bush Set (*2)
--Available in the market
--JAN code: 456212143 564 3

Rubber Bush Type L (*2)
--Available in the market
--JAN code: 456212143 784 5
Optical D Cable Type L/Double Hole Rubber Bush Set
installed on the housing


S-2000 (*3)(*4)
--Available in the market
--JAN code: 456212143 417 2

D-2000 Type4 (*3)(*4)
--Available in the market
--Jan Code: 456212143 211 6

Z-240 Type4 (*3)(*4)
--Available in the market
--JAN code: 456212143 251 2

(*1)
Contact Olympus Imaging Corp. for detail of camera/protector. INON Inc. confirms product compatibility based on a camera/protector available in Japan.

(*2)
Olympus PT-EP13 has fiber optics adapter for underwater use and above listed INON fiber optics product is directly plugged in the adapter.


(*3)
"S-TTL Auto" of S-2000 / Z-240 / D-2000 is usable only when flash mode of the E-M5 Mark II is set to “Fill-in flash”. INON strobe is not compatible with Olympus "wireless RC flash system".

(*4)
To use S-2000 / Z-240 / D-2000 in [Manual Mode] or [External Auto], set Advanced Cancel Circuit to [OFF] and flash mode of the E-M5 Mark II to "Manual".
When flash mode of the camera is set to "fill-in flash", "Manual Mode" more than -1.5 EV. setting (S-2000 / Z-240 / D-2000) and [External Auto] for the situation where strobe has to make -1.5 EV. or stronger (Z-240 / D-2000) is not usable.


INON LED flashlight LF2700-W / LF800-N / LF1100-W / LF1400-S / LF1000-S / LE700-W / LE700-S / LE350 is also usable to benefit underwater full HD movie function of E-M5 Mark II.


■ Lens System Compatibility with E-M5 Mark II / PT-EP13 (*1) ■

Attaching "M.ZUIKO DIGITAL ED12-50mm F3.5-6.3 EZ" on "E-M5 Mark II"
By using above combination with the Olympus Macro Lens Adapter, "PMLA-EP01" on PT-EP13 enable to install existing INON close-up lenses, "UCL-330" (*5), "UCL-165M67" (*5) and "UCL-100M67" (*6) directly on the lens ring (67mm) of PT-EP13.
Also, Underwater Micro Fisheye Lens, "UFL-M150 ZM80" (*7) is compatible.


Attaching "M.ZUIKO DIGITAL ED 60mm F2.8 Macro" on E-M5 Mark II
By using above combination with the Olympus Macro Lens Adapter, "PMLA-EP01" on "PT-EP13" enable to install existing INON close-up lenses, "UCL-330" (*5) and "UCL-165M67" (*5) directly on the lens ring (67mm) of PT-EP13.

INON wide conversion lenses are not compatible with either combination.


UCL-330 Close-up Lens (*5)
--Available in the market
--JAN code: 456212143 156 0


UCL-165M67 Close-up Lens (*5)
--Available in the market
--JAN code: 456212143 162 1


UCL-100M67 Close-up Lens (*6)
--Available in the market
--JAN code: 456212143 710 4

UFL-M150 ZM80 Underwater Micro Fisheye Lens (*6)(*7)
--Available in the market
--JAN code: 456212143 621 3
UCL-330 attached on Olympus E-M5 Mark II / PT-EP13 (upper left)
UCL-165M67 attached on Olympus E-M5 Mark II / PT-EP13 (upper right)
UCL-100M67 attached on Olympus E-M5 Mark II / PT-EP13 (lower left)
UFL-M150 ZM80 attached on Olympus E-M5 Mark II / PT-EP13 (lower right)

(*5)
Compatible with "M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ" and "M.ZUIKO DIGITAL ED 60mm F2.8 Macro". Other lenses have not been tested.

(*6)
Only compatible with "M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ"
Other lenses are not compatible.

(*7)
Optional "M27-M67 Mount Converter for UFL-M150 ZM80" is required.


■ Arm System Compatibility with E-M5 Mark II/PT-EP13 (*1) ■

Grip Base M1
--Available in the market
--JAN code: 456212143 605 3

D Holder
--Available in the market
--JAN code: 456212143 431 8

Shoe Base (*8)
--Available in the market
--JAN code: 456212143 356 4

Grip Base D4
--Available in the market
--JAN code: 456212143 430 1


The "Grip Base M1" is a base arm specifically designed for midsize underwater housing like micro four thirds digital SLR. The "Grip Base M1" is firmly attached on a housing with two tripod screws and equipped legs on the base provide stable placement of combined housing. As "Grip Base D4" (*9), wide variety of INON adapters/bases is compatible with the "Grip Base M1" and easy to set-up multiple lighting system with dual strobe configuration by attaching extra "D Holder".

The compact light arm "Shoe Base" (*8) is directly attached on the housing accessory shoe.

(*8)
When installing a strobe/LED light via INON "Shoe Base" on the "PT-EP13", the camera system will have neutral buoyancy. Adjust total underwater weight by using other accessories to get slightly negative buoyancy to avoid accidental rapid ascent.

(*9)
The "D Holder" of the "Grip Base D4" is for left side use only. When attaching on the right hand side of the housing, space between the D Holder and housing becomes extremely narrow and prevents you to hold the housing directly.


■ E-M5 Mark II / PT-EP13 (*1) set-up Example ■


•Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ
•Olympus PT-EP13 + Olympus Macro Lens Adapter PMLA-EP01
•UCL-165M67
•LF2700-W
•Single Light Holder LF
•Shoe Base


•Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ
•Olympus PT-EP13 + Olympus Macro Lens Adapter PMLA-EP01
•UCL-330
•S-2000 (with packaged "-0.5 White Diffuser for S-2000")
•Optical D Cable Type L/Double Hole Rubber Bush Set
•Grip Base M1
•Z Joint


•Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ
•Olympus PT-EP13 + Olympus Macro Lens Adapter PMLA-EP01
•UCL-100M67
•LF800-N
•Single Light LF
•Condenser lens LF-N (with packaged "Blue Filter LF-N")
•Grip Base M1
•D Holder Extension Bar
•M67 Lens Holder S
•Stick Arm S Set YS-MV
•M5 Joint
•M67 Lens Holder for Float Arm
•UCL-165M67


•Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ
•Olympus PT-EP13 + Olympus Macro Lens Adapter PMLA-EP01
•UFL-M150 ZM80
•M27-M67 Mount Converter for UFL-M150 ZM80
•LF1100-W (with packaged "Wide Filter LF-W") x2
•Single Light Holder LF x2
•Grip Base M1
•D Holder
•Z Adapter II x2
•Clamp III x4
•Stick Arm SS x2
•YS Adapter MV x2
•M5 Joint
•M67 Lens Holder for Float Arm
•UCL-165M67


■ E-M5 Mark II / PT-EP13 (*1) Sample Image ■


--Subject:
Moss fringehead
--Equipment:
Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ/PT-EP13+
PMLA-EP01, S-2000 Strobe (with packaged "-0.5 White Diffuser for S-2000") x 2
--Photo data:
•Without conversion lens (left)
Manual exposure (F11, 1/40, ISO250), Zoom telephoto end 50mm (100mm at 35mm film equivalent) S-2000: S-TTL Auto, Shooting distance: approx. 40cm (15.7in)
•With UCL-330 (upper right)
Manual exposure (F11, 1/40, ISO250), Zoom telephoto end 50mm (100mm at 35mm film equivalent), S-2000: S-TTL Auto, Shooting distance: approx. 30cm (11.8in)
•With UCL-165M67 (lower left)
Manual exposure (F13, 1/30, ISO250), Zoom telephoto end 50mm (100mm at 35mm film equivalent), S-2000: S-TTL Auto, Shooting distance: approx. 15cm (5.9in)
•With UCL-100M67 (lower right)
Manual exposure (F11, 1/40, ISO250), Zoom telephoto end 50mm (100mm at 35mm film equivalent), S-2000: S-TTL Auto, Shooting distance: approx. 10cm (3.9in)
--Photo by:
R. Hattori (INON INC.) at "Yokoiso beach", Atami, Shizuoka, Japan



--Subject/shooting distance:
Perch sculpin/approx. 10cm (3.9ft)
--Equipment:
Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ / PT-EP13 + PMLA-EP01, S-2000 Strobe (with packaged "-0.5 White Diffuser for S-2000”) x2, UCL-100M67
--Photo data:
Manual exposure (F14, 1/50, ISO200), Zoom telephoto end 50mm (100mm at 35 mm film equivalent), S-2000: S-TTL Auto
--Photo by:
F. Torii (INON INC.) at “Wannai”, Osezaki, Shizuoka, Japan



--Subject/shooting distance:
Young cuttlefish/approx. 10cm (3.9ft)
--Equipment:
Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 60mm F2.8 Macro/ PT-EP13, LF800-N, Condenser Lens LF-N (with packaged "Blue Filter LF-N"), UCL-165M67 x2
--Photo data:
Manual exposure (F5.6, 1/100, ISO320), LF800-N: Full mode
--Photo by:
R. Hattori (INON INC.) at "Wannai", Osezaki, Shizuoka, Japan


--Subject/shooting distance:
Young lumpfish /approx. 10cm (3.9ft)
--Equipment:
Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 60mm F2.8 Macro / PT-EP13, LF800-N, Condenser Lens LF-N x2 (with packaged "Blue Filter LF-N" x1), UCL-165M67
--Photo data:
Manual exposure (F22, 1/100, ISO800), LF800-N: Full mode
--Photo by:
R. Hattori (INON INC.) at Kawana, Shizuoka, Japan



--Subject/shooting distance:
Japanese bullhead shark/approx. 5cm (1.9ft)
--Equipment:
Olympus E-M5 Mark II + M.ZUIKO DIGITAL ED 12-50mm F3.5-6.3 EZ / PT-EP13+PMLA-EP01, S-2000 Strobe x2, -0.5 [4900K] Diffuser for S-2000 x2, UFL-M150 ZM80
--Photo data:
Manual exposure (F22, 1/40, ISO1600), Zoom telephoto end 50mm (100mm at 35mm film Equivalent), S-2000: S-TTL Auto
--Photo by:
R. Hattori (INON INC.) at "Yokoiso beach", Atami, Shizuoka, Japan


■ Relative information on INON web site ■


•Underwater "S-TTL" Auto strobe S-2000
http://www.inon.jp/products/strobe/s2000/top.html
•Underwater "S-TTL" Auto strobe D-2000
http://www.inon.jp/products/strobe/d2000/top.html
•Underwater "S-TTL" Auto strobe Z-240
http://www.inon.jp/products/strobe/z240/top.html

•Underwater LED handheld light LF2700-W
•Water-Proof LED handheld light LF800-N
•Water-Proof LED handheld light LF1100-W
•Underwater LED handheld light LF1400-S
•Water-Proof LED handheld light LE1000-S
•Underwater LED handheld light LE700-W
•Underwater LED handheld light LE700-S
•Water-Proof LED handheld light LE350
http://www.inon.jp/products/le_light/lineup.html

•M67 series attachment lens UCL-330 Close-up Lens
http://www.inon.jp/products/lens/ucl330/top.html
•M67 series attachment lens UCL-165M6 Close-up Lens
http://www.inon.jp/products/lens/ucl165m67/top.html
•[News] Release of UCL-100LD/UCL-100M67
http://www.inon.jp/products/lens/ucl100m67/top.html

•UFL-M150 ZM80 underwater micro fisheye lens
http://www.inon.jp/products/lens/uflm150zm80/top.html

•Grip Base M1
http://www.inon.jp/products/armsystem/base.html#gripbasem1
•Shoe Base
http://www.inon.jp/products/armsystem/base.html#shoebase


May 11, 2015
INON INC.


*Press release information is as of May 11, 2015 and subject to change without prior notice.
